VAM TOP®
The industry reference for premium connections.
The industry reference for premium connections.
VAM TOP® is recognized as setting the standard in reliability and performance in threaded and coupled premium connections. With a track record of over 30 years, the connection minimizes the risks that result from the most severe combined loads making it a suitable solution for even the most critical applications. The VAM TOP® product line also includes several specific designs for increased performances in torque (VAM TOP® HT), compression (VAM TOP® HC) or fatigue (VAM TOP® FE).
Benefits
Benefits
Extensive offer
Large range of sizes and grades, for all types of applications.
Field Proven
30 years of extensive track records on a wide variety of fields and applications.
High Performance
Large performance envelope and reliable design for easy running.
Performance
Performance, Application & Product Range
Performances
- In Tension, VAM TOP® is stronger than the pipe
- In Compression, rating up to 100% PBYS
- Excellent gas sealability
- Bending up to 30°/100 feet with sealability
- Extensive testing program according to the industry standards (including ISO 13679 CAL-IV)
- Field proven with numerous track records
Applications
- Production casing
- Tubing
- Liner
- Tie-back
- HP/HT well designs
Product Range
Product Range
- Sizes: From 2 3/8” to 16”
- Grades: Carbon, Martensitic stainless steel (13%CR & Super 13%CR), Duplex, Super Duplex and Nickel base Alloys
- Yield Strengths: 55 ksi to 140 ksi
- Enhanced products:
- VAM TOP® HT for high torques
- VAM TOP® HC for high compression
- VAM TOP® FE for fatigue enhanced
- Special clearance and special bevel options
- GRE Liner validated as per ISO 13679 CAL-IV
Discover VAM TOP ®
Resources
Documents & Resources
VAM TOP® Running Guidelines Poster
To help you optimize our connections' running, we have developed a dedicated poster summarizing running recommandations from our VAM® Field Service teams. To download it, please fill in the form below.
Stories
Customer Story
Stories
Customer Story
A continuous success story
VAM TOP® is the most widely used Threaded and Coupled premium connection in both tubing and casing sizes. Every minute since the beginning of its success story, a pipe threaded with VAM TOP® is run in a well. 20 million pipes More than 1,000 operators
