VAM® FJL
Integral flush for maximum clearance
VAM® FJL is a 100% inside and outside flush integral connection providing maximum clearance with optimum strength for liners, moderate depth casing, and tight-hole tubing strings.
Benefits
Benefits
Field proven
Extensive track record on a wide variety of fields and applications
Superior gas tightness
External and internal seals work independently of each other for 100% sealability
Slim design
100% flush design provides maximum clearance for deviated wells
Performance
Performance & Application
Performances
- Internal pressure rating: 100% pipe body
- Collapse rating: 100% API 5C3
- Tension capacity: up to 70% pipe body with sealability
- Compression capacity: up to 28% pipe body with sealability
- Bending capacity: up to 20°/100 ft
Applications
- Contingency liners, intermediate and production casing, tie-backs, tubing
- Highly deviated wells and horizontal wells
- Extended Reach Wells
Range
Product Range
- OD: 2 3/8’’ to 13 3/8’’
- Drifts: Standard, alternative, special
- Grades: Carbon Steel, including Sour Service, High Collapse grades, 13Cr, S13Cr and Corrosion Resistant Alloys
- YS: 80 ksi to 140 ksi
Resources
Documents & Resources
Stories
Customer Story
Stories
Customer Story
Field-proven sealability performance
VAM® FJL was notably selected for use in Mexico’s largest oil field as tubing in 9 5/8” 53.5# casing. This choice highlights its excellent sealability performance, thanks to its double metal-to-metal seal, and its proven success across various casing and tubing applications.
